Schneider Electric Phaseo ABT7 Voltage Transformer 230-400V 1x24V 100VA
Schneider Electric Phaseo ABT7 Voltage Transformer 230-400V 1x24V 100VA
Schneider Electric Phaseo ABT7 Voltage Transformer 230-400V 1x24V 100VA - Image 2
Schneider Electric Phaseo ABT7 Voltage Transformer 230-400V 1x24V 100VA - Image 3

Schneider Electric Phaseo ABT7 Voltage Transformer 230-400V 1x24V 100VA

£87.01 Incl. VAT

This ABL6 transformer supplies alternating current to control circuits while isolating them from mains power. It has a rated input voltage of 230V to 400V AC, a rated output voltage of 24V AC and a rated power of 100VA. It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining. It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors. · · · This ABL6 transformer supplies alternating current to control circuits while isolating them from mains power. · · It has a rated input voltage of 230V to 400V AC, a rated output voltage of 24V AC and a rated power of 100VA. · · It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining. · · It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors.

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: ABL6TS10B Categories: , , , , , Brand: Product Code: 2500278343

Description

Technical Specifications  Technical Specifications One-phase control transformer Depth 86 mm Width 85 mm Height 94 mm Relative short circuit voltage 7.86 % Primary voltage 3 – – – V Rated apparent power 100 VA Primary voltage 4 – – – V Primary voltage 1 230 – 400 V Primary voltage 2 385 – 415 V Primary voltage 5 – – – V Primary voltage 6 – – – V Primary voltage 7 – – – V Primary voltage 8 – – – V Primary voltage 9 – – – V Primary voltage 10 – – – V Secondary voltage 2 – – – V Secondary voltage 3 – – – V Secondary voltage 4 – – – V Secondary voltage 5 – – – V Secondary voltage 6 – – – V Secondary voltage 7 – – – V Secondary voltage 10 – – – V Secondary voltage 1 24 – 24 V Secondary voltage 8 – – – V Secondary voltage 9 – – – V Short-circuit-proof No Built as energy saving transformer No Built as safety transformer Yes Suitable for mounting on PCB No Modular version No Built as isolating transformer Yes Ring core No · Technical Data Sheet – Click to Download
