Phaseo ABT7 Voltage Transformer 230V-1x24V 100VA
Phaseo ABT7 Voltage Transformer 230V-1x24V 100VA
Phaseo ABT7 Voltage Transformer 230V-1x24V 100VA - Image 2
Phaseo ABT7 Voltage Transformer 230V-1x24V 100VA - Image 3

Phaseo ABT7 Voltage Transformer 230V-1x24V 100VA

£64.69 Incl. VAT

This ABT7 transformer supplies alternating current to control circuits while isolating them from mains power. It has a rated input voltage of 230V AC, a rated output voltage of 24V AC and a rated power of 100VA. It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining motor control centers (MCC). It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors. · · · This ABT7 transformer supplies alternating current to control circuits while isolating them from mains power. · · It has a rated input voltage of 230V AC, a rated output voltage of 24V AC and a rated power of 100VA. · · It offers an economic way to supply each consuming load individually, or by groups of loads, in applications such as mining, refining motor control centers (MCC). · · It is ideal for systems accepting low voltage AC power, such as motor protection relays, contactors.

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: ABT7ESM010B Categories: , , Brand: Part Number: 2500244360

Description

Technical Specifications  Technical Specifications One-phase control transformer Width 85.00 mm Height 94.00 mm Depth 86.00 mm Relative short circuit voltage 11.30 % Rated apparent power 100.00 VA Primary voltage 3 – – – V Primary voltage 4 – – – V Primary voltage 1 230.00 – 230.00 V Primary voltage 5 – – – V Primary voltage 6 – – – V Primary voltage 7 – – – V Secondary voltage 4 – – – V Secondary voltage 7 – – – V Secondary voltage 6 – – – V Secondary voltage 5 – – – V Secondary voltage 3 – – – V Primary voltage 10 – – – V Primary voltage 9 – – – V Primary voltage 8 – – – V Secondary voltage 10 – – – V Secondary voltage 1 24.00 – 24.00 V Secondary voltage 8 – – – V Secondary voltage 9 – – – V Built as energy saving transformer No Short-circuit-proof No Built as safety transformer Yes Suitable for mounting on PCB No Built as isolating transformer Yes Ring core No Modular version No · Technical Data Sheet – Click to Download
