Pilz E-Stop Safety Relay PNOZ Cat. 4 24V AC/DC 10A 3NO+1NC Aux.
Awaiting product image

Pilz E-Stop Safety Relay PNOZ Cat. 4 24V AC/DC 10A 3NO+1NC Aux.

£221.52 Incl. VAT

Pilz PNOZ X1 E-Stop safety relay is suitable for safety gate monitor, instantaneous E-STOP monitoring, limit switch applications. It supports various types of operating modes such as single-channel, automatic reset, manual reset. It features 24V AC/DC supply voltage, 5A maximum current at DC13 I (6 cycles/min), 5A maximum current at AC15, -10 to 55°C ambient temperature. It meets EN 60947-5-1, EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1 standard. · · · Current Rating: 10A, Control Voltage: 24V AC/DC · · Height: 87mm · · Material: PPO UL 94 V0 (Housing), ABS UL 94 V0 (Front) · · Mounting Type: DIN Rail · · Range: PNOZ · · Width: 22.5mm · · Weight: 175g · · Depth: 121mm · · IP Rating: IP54, IP40, IP20 · · Normal State Configuration: 3NO (Safety), 1NC (Auxiliary)

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 774300 Categories: , , , Brand: Product Code: 2500445543

Description

Technical Specifications  Technical Specifications Device for monitoring of safety-related circuits Width 9268 mm Performance level acc. to EN ISO 13849-1 Level e Depth 121 mm Height 87 mm Release-delay – 15 s With approval according to UL Yes With muting function No Rail mounting possible No With detachable clamps No With approval for BG BIA No Suitable for monitoring of position switches No Suitable for monitoring of emergency-stop circuits No Suitable for monitoring of valves No Suitable for monitoring of optoelectronic protection equipment No Suitable for monitoring of tactile sensors No Suitable for monitoring of magnetic switches No Suitable for monitoring of proximity switches No With start input Yes With feedback circuit No
