Portable OPS Mini PC, Intel Core I3 2310M, 8GB RAM+256GB Storage, Compact Desktop

Description

Product description

Hardware specifications Processor CPU Intel’s second-generation Sandy Bridge and third-generation Ivy Bridge laptop CPUs I3-2350M/I3-3110M/I5-2450M/I5-3210M/I7-3520M/I7-2620M Model Number HM76 Memory memory 1 x SO-DIMM DDR3 (maximum support 8GB) 4G D3/8G D3 Storage Type MSATA SSD/HDD Interface 1 x MSATA 1 x 7PINSATA interface Dominant frequency 2.3GHz/2.4GHz/2.5GHz-3.1GHz/2.9GHz-3.6GHz/2.7GHz-3.4GHz Hard disk 128G/256G kernel thread 2/4 WIFI WIFI Default 2.4G onboard WIFI Optional M.2 2.4G/5G dual-band WIFI + Bluetooth USB Front end USB 2.0 x 6 OPS end USB 2.0 x 3 COM port The board can provide 1 COM port connector and supports RS232. The OPS end supports serial port function (which can support RS232) with default TTL. CS(chipset) H61 Display Port Front-end output 1 HDMI 1.2 1920×1080 2K 60Hz 1 VGA 1920×1080 60Hz JAE end 1 HDMI 1.2 1920×1080 2K 60Hz Network port Built-in RTL8111H Gigabit network card 1 standard RJ45 interface with 10M/100M/1000M auto-sensing capability Audio Built-in high-definition sound card, audio output (green), MIC input (pink) Environment Operating temperature: 0 – 50℃; Storage temperature: -20 to 70℃; Operating humidity 5% – 95%, no condensation; Storage humidity: 5% – 95%, no condensation Case size 195*180*30/33/42MM (Thickness selectable) weight 3kg 1.
