Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20
Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20
Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20 - Image 2
Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20 - Image 3
Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20 - Image 4

Telemecanique Sensors Preventa 3 Pole Safety Switch Metal 1 NC + 2 NO 1 Entry Tapped M20

£102.49 Incl. VAT

This Preventa XCS Key Operated Safety Switch has an adjustable turret head and a Zamak body. This key operated safety switch for guard doors, with adjustable turret head switch, has a robust red coated Zamak body with one cable gland entry, allowing an easier installation. Its IP67 degree of protection makes it ideal for heavy duty use in harsh conditions. When wired as recommended in relevant standards, it conforms to category 4, performance level PL e, SIL 3 and complies withEN/ISO 13849-1, EN/IEC 61508. It simply ensures a -door-open machine stop- control on your machine, with maximal reliability. It secures the machine and system operation with a key, only available to authorized operators. · · · This Preventa XCS Key Operated Safety Switch has an adjustable turret head and a Zamak body. · · This key operated safety switch for guard doors, with adjustable turret head switch, has a robust red coated Zamak body with one cable gland entry, allowing an easier installation. · · Its IP67 degree of protection makes it ideal for heavy duty use in harsh conditions. · · When wired as recommended in relevant standards, it conforms to category 4, performance level PL e, SIL 3 and complies withEN/ISO 13849-1, EN/IEC 61508. · · It simply ensures a “door-open machine stop” control on your machine, with maximal reliability. · · Safety Reliability Data: B10d = 5000000 · · 5gn Vibration Resistance · · 10gn Shock Resistance / Class I Electrical Shock protection · · Without locking of actuator · · IP67 Degree of protection

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: XCSA502 Categories: , Brand: Product Code: 2500079297

Description

Technical Specifications  Technical Specifications Position switch with separate actuator Interface type None Type of interface for safety communication None Explosion safety category for dust None Explosion safety category for gas None Type of switching contact Slow-action switch Housing material Metal Degree of protection (IP rating) IP67K Type of electric connection Cable entry metrical Width sensor 40 mm Rated operation current Ie at AC-15, 230 V 3 A Length of sensor 44 mm Height of sensor 114 mm Number of contacts as change-over contact 0 Rated operation current Ie at DC-13, 125 V 0.55 A Rated operation current Ie at DC-13, 24 V – A Rated operation current Ie at AC-15, 24 V – A Number of safety auxiliary contacts 0 Rated operation current Ie at DC-13, 230 V 0.27 A Number of contacts as normally closed contact 1 Number of contacts as normally open contact 2 Rated operation current Ie at AC-15, 125 V 6 A Ambient temperature during operating -25 – 70 °C Suitable for safety functions Yes Forced opening Yes With status indication No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2188085
