Prysmian 6491X 10.0mm² Brown PVC Basec Cable 1-Core
£314.64 Incl. VAT
Prysmian 6491X is a single core, low voltage wiring cable designed for installation within conduit, trunking or inside fixed protected environments · · · Installation in surface mounted or embedded conduits, or similar closed systems and for fixed protected installation · · Green/Yellow for use as earth can be installed without mechanical protection. · · Length in metres: 100 · · No. of cores: 1 · · Product Packaging: Reel · · Material: PVC · · Standard: BS EN 50525-2-31
Description
Technical Specifications Technical Specifications Power cable < 1 kV, for fixed installations Core colour Brown Sheath colour Brown Conductor material Copper Core identification Colour Conductor surface Bare Conductor category Class 2 = stranded Core insulation material Polyvinyl chloride (PVC) Nominal cross sectional area of conductor 10 mm² Nominal voltage U 750 V Outer diameter approx. 6.3 mm Min. permitted bending radius, stationary application/permanent installation 38 mm Conductor Diameter 10 mm Nominal voltage U0 450 V Max. conductor temperature 70 °C Permitted cable outer temperature during assembling/handling 0 – 60 °C Low temperature resistant according to EN 60811-504+505+506 No Oil resistant according to IEC 60811-404 No · Technical Data Sheet – Click to Download
