Eaton RCBO Single Pole&Neutral Type C 25A 30mA 10kA

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Disconnection characteristic Undelayed Tripping characteristic (type/curve) C Frequency 50/60 Hz Degree of protection (IP rating) IP20 Leakage current type A Voltage type AC Recess depth 69.5 mm Rated voltage 240 V Rated current 25 A Power loss 6.5 W Width in number of modular spacings 1 Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Rated short-circuit breaking capacity according to EN 61009 10 kA Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Over voltage category 3 Rated short-circuit breaking capacity IEC 60947-2 0 kA Current limiting class 3 Number of protected poles 1 Pollution degree 2 Rated insulation voltage Ui 500 V Rated fault current 0.03 A Surge current capacity 0.25 kA Connectable conductor cross section solid-core 1 – 25 mm² Connectable conductor cross section multi-wired 1 – 25 mm² Ambient temperature during operating -25 – 40 °C Concurrently switching N-neutral No Anti-nuisance tripping version No With interlocking device No · Technical Data Sheet – Click to Download
