Schneider Electric RCBO SP Class Ac Type C 25A 30mA 10kA Plug-On

Brand: Schneider ElectricProduct code: SEE125C03Go Magpie Ref: 5060062388361

The Schneider LoadCentre KQ SEE125C03 is a 25 amp 30 milliamp single pole RCBO. This Schneider LoadCentre KQ RCBO has a click-in busbar for speed of installation and guaranteed connection, has a 10kA breaking capacity and has a trip free mechanism that operates even when the toggle is locked on. The LoadCentre KQ MCB’s are lockable in the on or off position and is suitable for any Schneider Loadcentre KQ A and B type distribution boards. · · · BS EN 61009 Compliant · · 10kA Breaking Capacity · · Speed of connection of Plug-On devices – guaranteed connection Plug-On devices · · Control type toggle · · Thermal-magnetic trip unit technology · · Its Visisafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. · · Its fast closing mechanism independent of manual operation improves its service life. · · This product is compliant with IEC 61009-1 and IEC 61009-2-2 standard. · · It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. · · The Ue operational voltage is 150VAC to 230VAC.

£76.96inc VAT£64.13 ex VAT
In stock — 12 available
UK deliveryStandard shipping is £2.99 inc VAT on eligible orders. Final delivery options are confirmed at checkout.
Quantity
1
✓ Secure checkout✓ UK customer support✓ Trusted suppliers
PRODUCT INFORMATION

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Tripping characteristic (type/curve) C Mounting method DIN rail Recess depth 70 mm Rated current 25 A Rated voltage 230 V Over voltage category 3 Rated impulse-withstand voltage (Uimp) 4 kV Pollution degree 3 Current limiting class 3 Number of protected poles 1 Number of poles (total) 2 Surge current capacity 0.25 kA Rated insulation voltage Ui 400 V Rated fault current 0.03 A Width in number of modular spacings 2 Rated short-circuit breaking capacity Icn according to EN 61009-1 10 kA Connectable conductor cross section solid-core 1 – 16 mm² Connectable conductor cross section multi-wired 1 – 16 mm² Ambient temperature during operating -25 – 55 °C Concurrently switching N-neutral Yes With interlocking device No Anti-nuisance tripping version No · Technical Data Sheet – Click to Download
