Relay Plug-In 4P Co Lockable 7A 24V Dc Test Button&Mech Ind
Relay Plug-In 4P Co Lockable 7A 24V Dc Test Button&Mech Ind
Relay Plug-In 4P Co Lockable 7A 24V Dc Test Button&Mech Ind - Image 2
Relay Plug-In 4P Co Lockable 7A 24V Dc Test Button&Mech Ind - Image 3

Relay Plug-In 4P Co Lockable 7A 24V Dc Test Button&Mech Ind

£8.48 Incl. VAT

Finder 55 Miniature General Purpose Plug-In Relay is available with lockable test button and mechanical indicator. The contact is made of silver nickel. Features lockable test button/mechanical flag indicator as standard on 2/4-pole types, coil indication/EMC suppression modules, 99 series timer module 86.30 options. · · · Cadmium free silver nickel contact · · Integral LED and coil suppression options · · Optional alternative mounting adaptors · · UL listing (certain relay/socket combinations) · · European patent · · The box has a clear cover, so you can easily see the contents of the box.

24 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 55.34.9.024.0040 Categories: , , Brand: Part Number: 2500348124

Description

Technical Specifications  Technical Specifications Switching relay Type of electric connection Plug-in connection Type of switch contact Single contact Drive, switching attitude Mono stable Voltage type for actuating DC Degree of protection (IP rating) IP40 Drive, polarization Polarity free Nominal current 7 A Width 20.7 mm Number of contacts as change-over contact 4 Depth 27.7 mm Complete with socket No With forced-guided contacts No Rated control supply voltage at DC 24 – 24 V Rated control supply voltage at AC 50 Hz 24 – 24 V Height 37.2 mm Number of contacts as normally closed contact 0 Number of contacts as normally open contact 0 With LED indication No With detachable clamps No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
