RM Switching Compact IP40 Ceiling Flush Mounted PIR Presence/Absence Detector 2-Channel
£155.94 Incl. VAT
CP PIR Presence/Absence Detector provide automatic control for lighting heating and ventilation loads. The PIR sensor can be mounted either flush into a ceiling tile or using a surface mounting box. The low-profile design means the unit can be mounted in a narrow ceiling void. No external control boxes are required as the unit is self-contained. The simple plug-in connections reduce installation time. The optional infrared remote handset allows the user to override the set up on some models. · · · Switching with lux level sensing · · Programmable via programming handset · · Absence detection functionality · · User handset available to control on/off and lux levels · · PRM Switching
6 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Motion detector Material Plastic Material qualifier Thermoplastic Degree of protection (IP rating) IP40 Mounting method Flush mounted Diameter 76 mm Height 68.5 mm Nominal voltage 230 V Voltage type AC Model Presence detector Sensor type Passive infrared Colour White Max. duty cycle 99 min Optimum mounting height 2.8 m Switching-on delay 10 s Max. starting current 6 A Diameter reach on floor 7 m Frequency 50 – 50 Hz Suitable for ceiling mounting Yes With DALI interface No · Technical Data Sheet – Click to Download
