Ronis Key Opeated Switch 22mm Round
£31.26 Incl. VAT
Siemens standard round RONIS key-operated selector switch made up of a silver coloured metal actuator surrounded by a high gloss silver colour metal ring. The mounting diameter is 22.3mm whereas the actuating element has a 29.5mm diameter. · · · Manner of function: Latching · · Actuating angle: 90° · · Number of switching positions: 2 · · Switch position for key distraction: O+I · · Mechanical sevice life: 300000 cycles · · Maximum operating frequency: 1800 1/h · · IP66/67/69 Degree of protection · · Vibration resistance: 5g (10-500Hz) · · Shock resistance: 50g · · Ambient temperature: -25 to 70°C
Out of stock
Description
Technical Specifications Technical Specifications Front element for selector switch Construction type lens Rectangular Type of control element Key Material front ring Metal Colour control element Silver Number of switch positions 2 Width opening 29.5 mm Height opening 49.4 mm Hole diameter 22.3 mm Suitable for illumination No With front ring Yes Switching function latching No Spring-return No · Technical Data Sheet – Click to Download
