Schletter Hanger Bolt Kit 10X200 Assembled

Hanger bolts For corrugated sheets (such as those of fiber cement) or trapezoidal sheet metal roofs, so-called fastening kits for corrugated roofs are used, comprising a special hanger bolt with EPDM gasket (will need additional mounting plate). Please note that thread lengths can deviate from the corresponding figures. · · · Hanger bolt kit with vulcanized EPDM gasket (UV-resistant) and 3 high-grade steel flange nuts (V4A), assembled · · Hanger bolts are used for fastening mounting rails to corrugated roofs and are screwed through the roof cladding and an adaptor plate bears the mounting rail. A UV-resistant EPDM sealing washer and collar are used to seal the drilled hole. · · With corrugated plates made of fibre cement or also with trapezoidal sheet metal roof coverings as well as with slate roof coverings, normally the fastening kit for corrugated roofs is used · · A special hanger bolt is screwed into the substructure through the roof cladding and bears the cross beam by means of a mounting plate
