Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu
Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu
Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu - Image 2
Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu - Image 3
Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu - Image 4

Schneider Electric Asymmetrical flashing relay, 0,1..1 s, 24..240 V AC, solid state outpu

£54.85 Incl. VAT

This Harmony RE17L timing relay can be set between 0.1 seconds and 100 hours, has an output rating of 0.7A, is 17.5mm wide and can be supplied with 24V to 240V AC. It also has a solid state output. It has one of market slimmest form-factors, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a sealable cover, simple and precise settings with rotary trimmers. This timer offers L, Li asymmetrical flashing functions. Solid state output, with no moving parts, longer product life and reduced sensitivity to vibrations. Single function timer for a simple integration in hard-wired logic schematics, ideal for refurbishment of old installations without using a PLC. · · · This Zelio RE17L timing relay can be set between 0.1 seconds and 100 hours, has an output rating of 0.7A, is 17.5mm wide and can be supplied with 24V to 240V AC. · · It also has a solid state output. · · It has one of market slimmest form-factors, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. · · It also offers a sealable cover, simple and precise settings with rotary trimmers. · · This timer offers L, Li asymmetrical flashing functions.

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: RE17LLBM Categories: , , Brand: Product Code: 2500633039

Description

Technical Specifications  Technical Specifications Timer relay Width 17.50 mm Nominal current – A Depth 72.00 mm Height 90.00 mm Number of outputs, undelayed, normally closed contact 0.00 Number of outputs, undelayed, normally open contact 0.00 Number of outputs, delayed, normally closed contact 0.00 Number of outputs, delayed, normally open contact 0.00 Number of outputs, delayed, change-over contact 0.00 Number of outputs, undelayed, change-over contact 1.00 Rated control supply voltage at DC – – – V Time range 0.10 – 360000.00 s Rated control supply voltage at AC 60 Hz 24.00 – 240.00 V Rated control supply voltage at AC 50 Hz 24.00 – 240.00 V Suitable for DIN rail (top hat rail) mounting Yes With semiconductor output Yes Pluggable on auxiliary contact block No Outputs, reversible delayed/undelayed No Function floating contact on de-energization No Function star-delta No Function pulse shaping No Clock function, starting with pause, variable No Clock function, starting with pulse, variable No Suitable as remote control No Function flashing, starting with pause, fixed time Yes Function flashing, starting with pulse, fixed time Yes Function delay-on energization No Function delay on de-energization No Function floating contact on energization No Remote operation possible No · Technical Data Sheet – Click to Download
