Schneider Electric Modicon STB Standard Analog Input Kit STB 2 I 15 Bits + Sign
Schneider Electric Modicon STB Standard Analog Input Kit STB 2 I 15 Bits + Sign
Schneider Electric Modicon STB Standard Analog Input Kit STB 2 I 15 Bits + Sign - Image 2

Schneider Electric Modicon STB Standard Analog Input Kit STB 2 I 15 Bits + Sign

£276.13 Incl. VAT

This product is part of the Modicon STB range, an offer of modular distributed I/O. This standard analogue input kit is an accessory kit of Programmable Logic Controllers (PLC) and Programmable Automation Controllers (PAC). It has 2 analogue inputs with 15bit plus sign resolution. This product is compatible with most major fieldbus networks. It is an analogue input kit with a rated supply voltage of 24V DC and a current consumption of 30mA at 5V DC for logic bus. It is an IP20 rated product. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines applications. This product is certified by FM Class 1 Division 2, ATEX category 3G, CE, UL, CSA and C-Tick. This kit is suitable for use with mounting base STBXBA1000 and power distribution module STBPDT3100/3105. The kit includes STBART0200 module, STBXTS1100, 6-terminal screw type connector, STBXBA1000 base and STBXTS2100, 6-terminal spring clamp connector. The Modicon STB distributed I/O solution is an open, modular input/output system that makes it possible to design automation islands managed by a master controller via a bus or communication network. · · · This product is part of the Modicon STB range, an offer of modular distributed I/O. · · This standard analogue input kit is an accessory kit of Programmable Logic Controllers (PLC) and Programmable Automation Controllers (PAC). · · It has 2 analogue inputs with 15bit plus sign resolution. · · This product is compatible with most major fieldbus networks. · · It is an analogue input kit with a rated supply voltage of 24V DC and a current consumption of 30mA at 5V DC for logic bus.

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: STBART0200K Category: Brand: Product Code: 2500250631

Description

Technical Specifications  Technical Specifications Fieldbus, decentr. periphery – analogue I/O module Width 128.30 mm Height 18.40 mm Number of HW-interfaces RS-232 0.00 Depth 70.00 mm Number of HW-interfaces RS-422 0.00 Number of analogue inputs 2.00 Number of HW-interfaces industrial Ethernet 0.00 Number of HW-interfaces RS-485 0.00 Number of analogue outputs 0.00 Number of HW-interfaces parallel 0.00 Number of HW-interfaces serial TTY 0.00 Number of HW-interfaces other 0.00 Number of HW-interfaces PROFINET 0.00 Number of HW-interfaces Wireless 0.00 Resolution of the analogue outputs – Bit Resolution of the analogue inputs 15.00 Bit Number of HW-interfaces USB 0.00 Supply voltage AC 50 Hz – – – V Supply voltage AC 60 Hz – – – V Supply voltage DC 24.00 – 24.00 V Input, resistor No Input, current No Input, resistance thermometer Yes Input, voltage Yes Supporting protocol for LON No Supporting protocol for PROFIBUS No Suitable for safety functions No Supporting protocol for ASI No Supporting protocol for INTERBUS No Supporting protocol for TCP/IP No Supporting protocol for CAN No Supporting protocol for KNX No Supporting protocol for MODBUS No Supporting protocol for SERCOS No Supporting protocol for PROFINET CBA No Supporting protocol for PROFINET IO No Supporting protocol for DeviceNet No Supporting protocol for Data-Highway No Supporting protocol for SUCONET No Output signal configurable No Output, voltage No Output, current No Input, thermocouple Yes Appendant operation agent (Ex ib) No Rail mounting possible Yes Analogue inputs configurable Yes Fieldbus connection over separate bus coupler possible Yes Rack-assembly possible Yes Appendant operation agent (Ex ia) No Front built-in possible No Input signal, configurable Yes System accessory Yes Wall mounting/direct mounting No Supporting protocol for SafetyBUS p No Supporting protocol for PROFIsafe No Supporting protocol for INTERBUS-Safety No Supporting protocol for DeviceNet Safety No Supporting protocol for AS-Interface Safety at Work No Supporting protocol for Foundation Fieldbus No Supporting protocol for EtherNet/IP No Radio standard GPRS No Radio standard WLAN 802.11 No Radio standard Bluetooth No Supporting protocol for other bus systems No Radio standard UMTS No Radio standard GSM No IO link master No Analogue outputs configurable No · Technical Data Sheet – Click to Download
