Schneider Electric NS800 MCCB TP 800A 70kA
£3,277.12 Incl. VAT
This is a Compact NS800H, 800A, 70kA at 415 VAC 50/60 Hz, 3 poles basic frame. It is adapted for withdrawable devices electrically operated, and it is an optimum choice for all standard applications. This basic frame is compatible with any type of trip unit which has to be ordered separately. It can be equipped with a variety of optional functions and accessories. The dimensions are 327mm (W) x 210mm (H) x 147mm (D). It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. · · · This is a Compact NS800H, 800A, 70kA at 415 VAC 50/60 Hz, 3 poles basic frame. · · It is adapted for withdrawable devices electrically operated, and it is an optimum choice for all standard applications. · · This basic frame is compatible with any type of trip unit which has to be ordered separately. · · It can be equipped with a variety of optional functions and accessories. · · The dimensions are 327mm (W) x 210mm (H) x 147mm (D).
Description
Technical Specifications Technical Specifications Moulded case circuit breaker (MCCB) Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 70 kA Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as change-over contact 0 Number of auxiliary contacts as normally closed contact 0 Rated permanent current Iu 800 A Number of poles 3 Overload release current setting – – – A Adjustment range short-term delayed short-circuit release – – – A Rated voltage 690 – 690 V Motor drive optional No Adjustment range undelayed short-circuit release – – – A DIN rail (top hat rail) mounting optional No Motor drive integrated Yes Switched-off indicator available No Complete device with protection unit No Integrated earth fault protection No Suitable for DIN rail (top hat rail) mounting No · Technical Data Sheet – Click to Download
