Schneider Electric Tesys GV2 Circuit Breaker Thermal-Magnetic 17-23A Screw Clamp Terminals
£180.85 Incl. VAT
TeSys GV motor circuit breaker, 3 poles (3P), 23A/690V, for high starting current peak motor applications 9-11kW@400V. It provides a thermal-magnetic protection with a thermal setting range 17-23A, a magnetic tripping level at 17xIn, high breaking capacity Icu 15kA@400V. Connection by screw clamp terminals. Start-stop control by toggle guaranteed for 100 000 cycles AC-3. It can be used for protection of 3-phase transformer applications. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). · · · TeSys GV motor circuit breaker, 3 poles (3P), 23A/690V, for high starting current peak motor applications 9-11kW@400V. · · It provides a thermal-magnetic protection with a thermal setting range 17-23A, a magnetic tripping level at 17xIn, high breaking capacity Icu 15kA@400V. · · Connection by screw clamp terminals. · · Start-stop control by toggle guaranteed for 100 000 cycles AC-3. · · It can be used for protection of 3-phase transformer applications.
Out of Stock
Description
Technical Specifications Technical Specifications Motor protection circuit-breaker Width 45.00 mm Number of poles 3.00 Rated permanent current Iu 23.00 A Rated operation power at AC-3, 400 V 9.00 kW Rated short-circuit breaking capacity Icu at 400 V, AC 15.00 kA Rated operation power at AC-3, 230 V 5.50 kW Height 89.00 mm Depth 78.50 mm Adjustment range undelayed short-circuit release 400.00 – 400.00 A Overload release current setting 17.00 – 23.00 A With thermal overload protection Yes Rated operating voltage 0.00 – 690.00 V With integrated under voltage release No With integrated auxiliary switch No Phase failure sensitive Yes · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2224938
