Schneider Electric Tesys K Auxiliary Contact Block 1 NO + 3 NC Screw-Clamps Terminals

TeSys K, Auxiliary contact block, 1 NO+3 NC, screw-clamps terminals. range of product: TeSys K, TeSys K control relay – range: TeSys – device short name: LA1 – product or component type: auxiliary contact block – pole contact composition: 1 NO + 3 NC – connections – terminals: screw clamp terminals 1 cable 0.34…1.5 mm² – cable stiffness: flexible – with cable end, screw clamp terminals 1 cable 0.75…4 mm² – cable stiffness: flexible – without cable end, screw clamp terminals 1 cable 1.5…4 mm² – cable stiffness: solid, screw clamp terminals 2 cable 0.34…1.5 mm² – cable stiffness: flexible – with cable end, screw clamp terminals 2 cable 0.75…4 mm² – cable stiffness: flexible – without cable end, screw clamp terminals 2 cable 1.5…4 mm² – cable stiffness: solid. · · · TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). · · It provides 1NO+3NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. · · Depth: 35mm · · Front mounting by clip-on, it procures high reliability and durability. · · Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).
