Schneider Electric TeSys K Contactor 3-Pole (3NO) AC-3 440V 9A 220-230V AC Coil
Schneider Electric TeSys K Contactor 3-Pole (3NO) AC-3 440V 9A 220-230V AC Coil
Schneider Electric TeSys K Contactor 3-Pole (3NO) AC-3 440V 9A 220-230V AC Coil - Image 2
Schneider Electric TeSys K Contactor 3-Pole (3NO) AC-3 440V 9A 220-230V AC Coil - Image 3

Schneider Electric TeSys K Contactor 3-Pole (3NO) AC-3 440V 9A 220-230V AC Coil

£80.80 Incl. VAT

TeSys K contactor, 3 poles (3NO), 9A/690V AC-3, for motor applications up to 4kW@400V. It provides a 220-230V 50/60Hz AC coil with rectifier incorporated and surge suppressor, 1NC built-in auxiliary contact, connection by screw clamp terminals. Silent contactor recommended for use in areas sensitive to noise and high interference mains supplies. Very compact, DIN-rail mounting and screw fixing, it procures reliability and durability to standard applications. Multi-standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach). · · · TeSys K contactor, 3 poles (3NO), 9A/690V AC-3, for motor applications up to 4kW@400V. · · It provides a 220-230V 50/60Hz AC coil with rectifier incorporated and surge suppressor, 1NC built-in auxiliary contact, connection by screw clamp terminals. · · Silent contactor recommended for use in areas sensitive to noise and high interference mains supplies. · · Very compact, DIN-rail mounting and screw fixing, it procures reliability and durability to standard applications. · · Multi-standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach). · · Depth: 57mm · · Normal State Configuration: 3 No

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: LC7K0901M7 Categories: , , , , , Brand: Product Code: 2500658510

Description

Technical Specifications  Technical Specifications Power contactor, AC switching Number of main contacts as normally open contact 3.00 Number of normally closed contacts as main contact 0.00 Number of auxiliary contacts as normally open contact 0.00 Number of auxiliary contacts as normally closed contact 1.00 Rated operation power at AC-3, 400 V 4.00 kW Rated operation current Ie at AC-1, 400 V 20.00 A Rated operation power NEMA – kW Rated operation current Ie at AC-4, 400 V 6.00 A Rated operation power at AC-4, 400 V 2.20 kW Rated control supply voltage at DC – – – V Rated operation current Ie at AC-3, 400 V 9.00 A Rated control supply voltage at AC 60 Hz 220.00 – 230.00 V Rated control supply voltage at AC 50 Hz 220.00 – 230.00 V Modular version No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2187998
