Schneider Electric Tesys K Contactor 4P (2 NO + 2 NC) AC-1 <= 440V 20A 48V DC Coil
Schneider Electric Tesys K Contactor 4P (2 NO + 2 NC) AC-1 <= 440V 20A 48V DC Coil
Schneider Electric Tesys K Contactor 4P (2 NO + 2 NC) AC-1 <= 440V 20A 48V DC Coil - Image 2
Schneider Electric Tesys K Contactor 4P (2 NO + 2 NC) AC-1 <= 440V 20A 48V DC Coil - Image 3

Schneider Electric Tesys K Contactor 4P (2 NO + 2 NC) AC-1 <= 440V 20A 48V DC Coil

£46.84 Incl. VAT

TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. It provides a 48V DC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). · · · TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. · · Number of Poles: 4P · · It provides a 48V DC coil, without built-in auxiliary contact, connection by screw clamp terminals. · · For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. · · Very compact (45mm width), DIN-rail mounting or screw fixing. · · Depth: 57mm · · Normal State Configuration: 2 No + 2 Nc

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: LP1K09008ED Categories: , , Brand: Product Code: 2500153077

Description

Technical Specifications  Technical Specifications Power contactor, AC switching Number of normally closed contacts as main contact 2 Number of main contacts as normally open contact 2 Rated operation current Ie at AC-3, 400 V – A Rated operation power at AC-3, 400 V – kW Rated operation power NEMA – kW Rated operation current Ie at AC-4, 400 V – A Rated operation current Ie at AC-1, 400 V 20 A Rated operation power at AC-4, 400 V – kW Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as normally open contact 0 Rated control supply voltage at AC 50 Hz – – – V Rated control supply voltage at AC 60 Hz – – – V Rated control supply voltage at DC 48 – 48 V Modular version No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2187998
