Schneider Electric Merlin Trip Unit 3P 16A

SKU: C103TM016Go Magpie ID: 5060062359590

This MicroLogic 2.2 is a 3 poles 3d electronic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 40A rating electronic trip unit is an optimum choice for all standard and specific applications. It embeds an adjustable long time protection against overloads. It provides also an adjustable short-time protection and a fixed instantaneous protection against short-circuits. MicroLogic 2.2 indicates overloads with Alarm LEDs. The green Ready LED flashes if the circuit breaker is ready to trip. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame. · · · Schneider Electric green signature style for the entire ComPacT range · · Estimated 40% reduction of wiring time for panel builders · · Experience easier installation thanks to a new ergonomic front-plate design · · Gain the confidence that all auxiliaries are on the right spot, and check that you have the right coil rating · · Ergonomic new toggle for easier breaker manual operation

£110.30inc VAT£91.92 ex VAT
In stock
UK deliveryDelivery options and final cost are confirmed at checkout.
Quantity
1
✓ Secure checkout✓ UK customer support✓ Trusted suppliers
PRODUCT INFORMATION

Description

Technical Specifications  Technical Specifications Trip block for power circuit-breaker Short-circuit release function Undelayed Type of motor protection Thermal/magnetic release Voltage type (operating voltage) AC Width 104.7 mm Height 60.6 mm Rated permanent current Iu 16 A Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as normally closed contact 0 Rated switch current 16 A Number of auxiliary contacts as change-over contact 0 Depth 88.2 mm Number of poles 3 Supply voltage AC 60 Hz – – – V Overload release current setting 11.2 – 16 A Supply voltage DC – – – V Operating voltage at AC 50 Hz 690 – 690 V Operating voltage at AC 60 Hz 690 – 690 V Operating voltage at DC – – – V Current setting undelayed short-circuit release 190 – 190 A External power supply required No With ground fault protection function No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2205407
