Schneider Merlin Trip Unit 4P 125A

Description

Technical Specifications  Technical Specifications Trip block for power circuit-breaker Type of motor protection Thermal/magnetic release Voltage type (operating voltage) AC Short-circuit release function Undelayed Height 60.6 mm Width 139.7 mm Rated permanent current Iu 125 A Depth 88.2 mm Number of poles 4 Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as change-over contact 0 Operating voltage at AC 50 Hz 690 – 690 V Supply voltage DC – – – V Supply voltage AC 60 Hz – – – V Overload release current setting 87.5 – 125 A Rated switch current 125 A Number of auxiliary contacts as normally closed contact 0 Operating voltage at AC 60 Hz 690 – 690 V Operating voltage at DC – – – V Current setting undelayed short-circuit release 1250 – 1250 A External power supply required No With ground fault protection function No · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2205407
