Schneider Merlin Trip Unit 4P 200A

£474.91 Incl. VAT

This TM200D is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 250 circuit breakers. This 200A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame. · · · Schneider Electric green signature style for the entire ComPacT range · · Estimated 40% reduction of wiring time for panel builders · · Experience easier installation thanks to a new ergonomic front-plate design · · Gain the confidence that all auxiliaries are on the right spot, and check that you have the right coil rating · · Ergonomic new toggle for easier breaker manual operation

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C254TM200 Categories: , , Brand: Part Number: 2501503768

Description

Technical Specifications  Technical Specifications Trip block for power circuit-breaker Short-circuit release function Undelayed Type of motor protection Thermal/magnetic release Voltage type (operating voltage) AC Width 139.7 mm Rated permanent current Iu 200 A Number of auxiliary contacts as change-over contact 0 Number of auxiliary contacts as normally open contact 0 Depth 88.2 mm Supply voltage DC – – – V Supply voltage AC 60 Hz – – – V Overload release current setting 140 – 200 A Height 60.6 mm Number of poles 4 Rated switch current 200 A Number of auxiliary contacts as normally closed contact 0 Operating voltage at AC 50 Hz 690 – 690 V Operating voltage at AC 60 Hz 690 – 690 V Operating voltage at DC – – – V Current setting undelayed short-circuit release 1000 – 2000 A With ground fault protection function No External power supply required No · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2205407
