Schneider Merlin Trip Unit 4P 32A
Schneider Merlin Trip Unit 4P 32A
Schneider Merlin Trip Unit 4P 32A - Image 2
Schneider Merlin Trip Unit 4P 32A - Image 3
Schneider Merlin Trip Unit 4P 32A - Image 4

Schneider Merlin Trip Unit 4P 32A

£167.99 Incl. VAT

This TM32D is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160 circuit breakers. This 32A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame. · · · Schneider Electric green signature style for the entire ComPacT range · · Estimated 40% reduction of wiring time for panel builders · · Experience easier installation thanks to a new ergonomic front-plate design · · Gain the confidence that all auxiliaries are on the right spot, and check that you have the right coil rating · · Ergonomic new toggle for easier breaker manual operation

2 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C104TM032 Categories: , , Brand: Part Number: 2501491486

Description

Technical Specifications  Technical Specifications Trip block for power circuit-breaker Short-circuit release function Undelayed Type of motor protection Thermal/magnetic release Voltage type (operating voltage) AC Rated permanent current Iu 32 A Depth 88.2 mm Height 60.6 mm Rated switch current 32 A Supply voltage AC 60 Hz – – – V Overload release current setting 22.4 – 32 A Number of auxiliary contacts as change-over contact 0 Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as normally open contact 0 Number of poles 4 Width 139.7 mm Supply voltage DC – – – V Operating voltage at AC 50 Hz 690 – 690 V Operating voltage at AC 60 Hz 690 – 690 V Operating voltage at DC – – – V Current setting undelayed short-circuit release 400 – 400 A With ground fault protection function No External power supply required No · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2205407
