Siemens MCB Heavy Duty TP Type C 100A 10Ka
Siemens MCB Heavy Duty TP Type C 100A 10Ka
Siemens MCB Heavy Duty TP Type C 100A 10Ka - Image 2

Siemens MCB Heavy Duty TP Type C 100A 10Ka

£215.21 Incl. VAT

Miniature circuit breaker 400 V 10kA, 3-pole, C, 100 A, D=70 mm The miniature circuit breaker is the fuse for short-circuit protection. The miniature circuit breakers from Siemens, as an important component of the SENTRON protective components for electronic installations, provide effective protection for personnel and plants by reliably shutting down in the event of an overload or short-circuit. User-friendly mounting and connection technology, standardized additional components and an integrated design – these are the characteristics of the device family. Whether for infrastructure or for industrial requirements, Siemens provides miniature circuit breakers for all applications and every application area. The Siemens miniature circuit breakers are characterized primarily by: 1. Effective personnel, investment and plant protection against overload and short-circuits. 2. A wide variety of standardized accessories, easy to install and replaceable at any time. 3. Reliable safety during installation due to standard reach-around and touch protection. 4. Clearly visible switch position indicator. 5. The data matrix code on the front of the device provides quick and easy access to information on all aspects of miniature circuit breakers. 6. Optimized technology for your safety – only from Siemens. · · · CIRCUIT BREAKER 10KA 3P C100 1,5MW

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 5SP4391-7 Brand: Product Code: 2500118181

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Tripping characteristic (type/curve) C Degree of protection (IP rating) IP20 Rated current 100 A Voltage type AC Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Recess depth 70 mm Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Over voltage category 3 Pollution degree 3 Number of poles (total) 3 Rated voltage 400 V Rated insulation voltage Ui 440 V Frequency 50 – 50 Hz Width in number of modular spacings 4.5 Connectable conductor cross section solid-core 25 – 50.0 mm² Connectable conductor cross section multi-wired 25 – 50.0 mm² Additional equipment possible Yes Concurrently switching N-neutral No · Technical Data Sheet – Click to Download
