Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray
Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray
Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray - Image 2
Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray - Image 3
Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray - Image 4

Swifts Legrand Bend 90° Angle Flat 225mm Hot Dipped Galvanised for Cable Tray

£52.40 Incl. VAT

MRFB225G is a 90° Flat Bend made of hot dipped galvanised steel finish and has integral coupling tabs. It is suitable for use with the 225mm Swift cable tray systems. · · · Medium duty capability · · Simple Installation · · 90° Angle

7 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: MRFB225G Categories: , , Brand: Part Number: 2500025044

Description

Technical Specifications  Technical Specifications Bend/riser for cable tray Material Steel Change of direction Horizontal Colour Grey Construction type Rigid bend Angle 90° Model Integrated coupler Deflection (angle) 90° Surface protection Hot dip galvanized Material thickness 1.2 mm Inner radius 125 mm RAL number – NATO-mounting holes No Side wall perforation No Working temperature -20 – 120 °C Suitable for cable tray height 25 mm Suitable for cable tray width 225 mm Mounting perforation in base Yes With cover No Suitable for circuit integrity No Stainless steel, pickled No · Technical Data Sheet – Click to Download
