Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A
Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A
Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A - Image 2
Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A - Image 3
Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A - Image 4

Switch Disconnector ComPacT NSX100NA, 3 poles, 100 A, AC22A, AC23A

£331.66 Incl. VAT

· · This ComPacT NSX100NA is a complete 3 poles switch disconnector. · · It is used to control and isolate electrical distribution circuits and it requires an upstream protection. · · The operational current is 100A at 415VAC 50/60Hz for AC22A and AC23A utilization categories. · · The operational voltage is 690VAC 50/60Hz. · · It comes with a variety of optional functions and accessories common with ComPacT NSX circuit breakers. · · The dimensions for this 3 poles version are 105mm x 161mm x 86mm. · · It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

1 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C103100S Categories: , , Brand: Part Number: 2501503848

Description

Technical Specifications  Technical Specifications Switch disconnector / isolator Colour control element Black Device construction Built-in device fixed built-in technique Degree of protection (IP), front side IP30 Type of electrical connection of main circuit Screw connection Type of control element Toggle Number of poles 3 Number of auxiliary contacts as normally closed contact 0 Rated operation power at AC-3, 400 V – kW Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 100 A Rated short-time withstand current lcw 1.8 kA Conditioned rated short-circuit current Iq – kA Number of auxiliary contacts as change-over contact 5 Max. rated operation voltage Ue AC 690 V Motor drive integrated No Version as emergency stop installation No Rated operating voltage 690 – 690 V Switching power at 400 V – kW Rated permanent current at AC-23, 400 V 100 A Rated permanent current at AC-21, 400 V 100 A Rated operation power at AC-23, 400 V – kW Number of switches 1 Version as main switch Yes Version as maintenance-/service switch Yes Version as safety switch No Version as reversing switch No Motor drive optional Yes Suitable for floor mounting Yes Suitable for front mounting 4-hole Yes Suitable for front mounting centre No Voltage release optional Yes Interlockable Yes Suitable for distribution board installation Yes Suitable for intermediate mounting No
