Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A
Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A
Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A - Image 2
Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A - Image 3
Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A - Image 4

Schneider Electric Switch Disconnector ComPacT NSX100NA, 4 poles, 100 A, AC22A, AC23A

£349.99 Incl. VAT

· · This ComPacT NSX100NA is a complete 4 poles switch disconnector. · · It is used to control and isolate electrical distribution circuits and it requires an upstream protection. · · The operational current is 100A at 415VAC 50/60Hz for AC22A and AC23A utilization categories. · · The operational voltage is 690VAC 50/60Hz. · · It comes with a variety of optional functions and accessories common with ComPacT NSX circuit breakers. · · The dimensions for this 4 poles version are 140mm x 161mm x 86mm. · · It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C104100S Categories: , , Brand: Product Code: 2501491461

Description

Technical Specifications  Technical Specifications Switch disconnector / isolator Colour control element Black Degree of protection (IP), front side IP30 Device construction Suitable for fixed installation Type of control element Toggle Type of electrical connection of main circuit Screw connection Rated operation power at AC-3, 400 V – kW Rated short-time withstand current lcw 1.8 kA Number of poles 4 Conditioned rated short-circuit current Iq – kA Number of auxiliary contacts as change-over contact 5 Rated operation power at AC-23, 400 V – kW Max. rated operation voltage Ue AC 690 V Number of switches 1 Rated permanent current at AC-21, 400 V 100 A Switching power at 400 V – kW Rated permanent current at AC-23, 400 V 100 A Rated permanent current Iu 100 A Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as normally closed contact 0 Rated operating voltage 690 – 690 V Voltage release optional Yes Interlockable Yes Version as emergency stop installation No Motor drive integrated No Version as main switch Yes Version as maintenance-/service switch Yes Version as safety switch No Version as reversing switch No Motor drive optional Yes Suitable for front mounting 4-hole Yes Suitable for front mounting centre No Suitable for distribution board installation Yes Suitable for intermediate mounting No · Technical Data Sheet – Click to Download
