Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A
Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A
Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A - Image 2
Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A - Image 3
Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A - Image 4

Switch Disconnector ComPacT NSX400NA, 4 poles, 400 A, AC22A, AC23A

£1,532.65 Incl. VAT

· · This ComPacT NSX400NA is a complete 4 poles switch disconnector. · · It is used to control and isolate electrical distribution circuits. It requires an upstream protection. · · The operational current is 400A at 415VAC 50/60Hz for AC22A and AC23A utilization categories. · · The operational voltage is 690VAC 50/60Hz. · · It comes with a variety of optional functions and accessories common with ComPacT NSX circuit breakers. · · The dimensions for this 4 poles version are 185mm x 255mm x 110mm. · · It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

2 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: C404400S Categories: , , Brand: Part Number: 2501503856

Description

Technical Specifications  Technical Specifications Switch disconnector / isolator Device construction Built-in device fixed built-in technique Colour control element Black Degree of protection (IP), front side IP30 Type of electrical connection of main circuit Screw connection Type of control element Toggle Number of auxiliary contacts as normally closed contact 0 Rated operation power at AC-3, 400 V – kW Number of poles 4 Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 400 A Rated short-time withstand current lcw 5 kA Switching power at 400 V – kW Rated permanent current at AC-23, 400 V 400 A Rated permanent current at AC-21, 400 V 400 A Rated operation power at AC-23, 400 V – kW Max. rated operation voltage Ue AC 690 V Number of auxiliary contacts as change-over contact 5 Conditioned rated short-circuit current Iq – kA Number of switches 1 Motor drive integrated No Suitable for floor mounting Yes Version as reversing switch No Version as emergency stop installation No Version as safety switch No Version as maintenance-/service switch Yes Version as main switch Yes Rated operating voltage 690 – 690 V Motor drive optional Yes Suitable for front mounting 4-hole Yes Suitable for front mounting centre No Voltage release optional Yes Interlockable Yes Suitable for distribution board installation Yes Suitable for intermediate mounting No
