Schneider Electric Switch Disconnector Double Pole 63A 400V
Schneider Electric Switch Disconnector Double Pole 63A 400V
Schneider Electric Switch Disconnector Double Pole 63A 400V - Image 2
Schneider Electric Switch Disconnector Double Pole 63A 400V - Image 3

Schneider Electric Switch Disconnector Double Pole 63A 400V

£10.60 Incl. VAT

The Schneider Electric EZ9S16263 is a 63 amp double pole main switch disconnector that will fit any Schneider Electric Easy9 consumer unit. · · · Positive contact indication · · Suitable for isolation according to BSEN 60947-3 · · Manual control on front face · · 63A Rated · · 2 Pole · · For use with Easi 9 range of consumer units · · IP20 · · The Ue rated operational voltage is 400VAC. · · The Ui rated insulation voltage is 500VAC. · · It has a Uimp rated impulse withstand voltage of 4kV. The operating frequency is 50Hz or 60Hz.

✓ In stock – Delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: EZ9S16263 Categories: , , Brand: Product Code: 2500605630

Description

Technical Specifications  Technical Specifications Switch disconnector / isolator Number of poles 2 Rated short-time withstand current lcw 0.76 kA Number of auxiliary contacts as normally open contact 0 Rated permanent current Iu 63 A Number of auxiliary contacts as change-over contact 0 Max. rated operation voltage Ue AC 400 V Number of auxiliary contacts as normally closed contact 0 Suitable for front mounting centre Yes Version as reversing switch No Rated operating voltage 400 – 400 V Motor drive optional No Voltage release optional No Interlockable No Suitable for distribution board installation Yes Suitable for intermediate mounting Yes Suitable for front mounting 4-hole Yes Motor drive integrated No Version as main switch No Version as maintenance-/service switch No Version as safety switch No Version as emergency stop installation No · Technical Data Sheet – Click to Download
