Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M
Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M
Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M - Image 2
Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M - Image 3
Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M - Image 4

Telemecanique Sensors Inductive Sensor Xs6m12 L53mm Brass Sn4mm 24-240V AC/DC Cable 2M

£77.57 Incl. VAT

This XS cylindrical (M12 thread) inductive proximity sensor has a PPS sensing face and a nickel plated brass case. It has a supply voltage of 24V to 240V AC/DC. This general purpose threaded cylindrical inductive proximity sensor is flush mountable and has an increased sensing range. It is mountable directly on a surface or bracket, thanks to its outer thread and twin nuts. Corrosion-resistant and non-magnetic nickel plated brass provides magnetic shielding to the sensor, better accuracy and immunity to magnetic disturbance. It has an annular LED for easy sensor status viewing, setup and troubleshooting. IP65 and IP68 protection makes this product ready for the harshest environments. It can operate in very cold (-25°C) and hot environments (+70°C). It features double insulation for better people and system protection from electrical shocks. It is CSA, UL certified. · · · This XS cylindrical (M12 thread) inductive proximity sensor has a PPS sensing face and a nickel plated brass case. · · It has a supply voltage of 24V to 240V AC/DC. · · This general purpose threaded cylindrical inductive proximity sensor is flush mountable and has an increased sensing range. · · It is mountable directly on a surface or bracket, thanks to its outer thread and twin nuts. · · Corrosion-resistant and non-magnetic nickel plated brass provides magnetic shielding to the sensor, better accuracy and immunity to magnetic disturbance. · · It has an annular LED for easy sensor status viewing, setup and troubleshooting. · · IP65 and IP68 protection makes this product ready for the harshest environments. · · It can operate in very cold (-25°C) and hot environments (+70°C). · · It features double insulation for better people and system protection from electrical shocks. · · It is CSA, UL certified.

Out of Stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: XS612B1MAL2 Categories: , , , , , Brand: Product Code: 2500212853

Description

Technical Specifications  Technical Specifications Inductive proximity switch Interface type None SIL according to IEC 61508 None Performance level acc. to EN ISO 13849-1 None Type of interface for safety communication None Explosion safety category for dust None Explosion safety category for gas None Coating housing Nickel-plated Construction type housing Cylinder, screw-thread Type of switching output 2-wire Mechanical mounting condition for sensor Concise Interference resistance to magnetic fields Immune against magnetic DC- and AC-field Housing material Metal Type of electric connection Cable radial Type of switch function Normally open contact Voltage type AC/DC Type of actuation Metallic Target Switching distance 4 mm Max. output current at protected output 200 mA Length of sensor 50 mm Diameter sensor 12 mm Number of protected semiconductor outputs 0 Number of protected contact energized outputs 0 Number of contact energized outputs with signalling function 0 Number of semiconductor outputs with signalling function 0 Height of sensor – mm Width sensor – mm Switching frequency 1000 Hz Rated control supply voltage at AC 50 Hz – V Rated control supply voltage at AC 60 Hz – V Supply voltage 24 – 240 V Rated control supply voltage at DC – V Suitable for safety functions No With monitoring function downstream switching devices No Cascadable No Compression-resistant No · Technical Data Sheet – Click to Download
