Telemecanique Sensors Pressure switch XMLB 10 bar, adjustable scale 2 thresholds, 1 C/O
£214.55 Incl. VAT
Pressure switch XMLB 10 bar, adjustable scale 2 thresholds, 1 C/O. range of product: OsiSense XM – product or component type: electromechanical pressure sensor – device short name: XMLB – pressure sensor size: 10 bar – controlled fluid: air (0…70 °C), fresh water (0…70 °C), hydraulic oil (0…70 °C) – electrical connection: 1 connector Pg 13, screw-clamps terminals 1 x 0.5…2 x 2.5 mm² – AWG gauge: AWG 20…AWG 14 – product specific application: – – electrical circuit type: control circuit – scale type: adjustable differential – local display: with – adjustable range of switching point on rising pressure: 0.7…10 bar – adjustable range of switching point on falling pressure: 0.13…9.15 bar – possible differential maximum at high setting: 7.5 bar – maximum permissible accidental pressure: 22.5 bar – destruction pressure: 45 bar – pressure actuator: diaphragm – materials in contact with fluid: FPM, FKM, zinc alloy – enclosure material: zinc alloy – [In] rated current: 0.1 A, R300, DC-13 (Ue = 250 V) conforming to EN/IEC 60947-5-1, 1.5 A, B300, AC-15 (Ue = 240 V) conforming to EN/IEC 60947-5-1, 3 A, B300, AC-15 (Ue = 120 V) conforming to EN/IEC 60947-5-1. · · · This XMLB electromechanical pressure switch has an adjustable differential for regulation of 2 thresholds and a zinc alloy body with a range scale window. · · This pressure switch is designed for regulation of pressure between 2 thresholds for air, fresh water and hydraulic oils at temperatures up to 70°C. · · It is fixed directly on tubage. · · It provides zinc alloy enclosure for robust performance. · · 5 million cycles mechanical durability for minimum required maintenance on your pressurized fluid circuits. · · It complies with CCC, EN/IEC 60947-5-1, CSA C22.2 No.14, LROS, UL 508, EAC, BV.
Description
Technical Specifications Technical Specifications Pressure switch Degree of protection (IP rating) IP66 Type of electric connection Screw connection Width 35 mm Height 113 mm Rated operation power at AC-3, 400 V – kW Depth 75 mm Diameter – mm Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as change-over contact 1 Number of auxiliary contacts as normally closed contact 0 Rated operation current Ie at AC-1, 400 V – A Rated operation current Ie at AC-3, 400 V – A Bursting pressure 45 bar Number of normally closed contacts as main contact 0 Number of main contacts as normally open contact 0 Initial value measuring range pressure – Pa End value measuring range pressure – Pa Switching capacity at AC-3, 240 V – kA Max. operating pressure 10000 hPa Max. test pressure 22.5 bar Pressure-switching differential 6.65 bar Engaging pressure 0.7 – 10 bar Initial setting 700 – 10000 hPa Switch off pressure 0.13 – 9.15 bar Rated voltage Ue at AC 50 Hz 120 – 240 V Rated voltage Ue at AC 60 Hz 120 – 240 V End setting 130 – 9150 hPa Rated voltage Ue at DC 250 – 250 V Adjustable current range – A Medium temperature 0 – 70 °C Electronic version Yes Suitable as guard Yes Display No Suitable as 2-point controller Yes With manual on/off switch No Suitable as limiter No With hand operation No Explosion-proof No · Technical Data Sheet – Click to Download
