TeSys D Clip-On Mounting Suppressor Module 110-240VAC
£25.94 Incl. VAT
TeSys D suppressor module, for LC1D40A-D80A, LC1DT60A-DT80A contactors. To be used with 380-415V AC control circuit voltage, it provides a RC protection limiting the transient voltage to 3 Uc max. Clip-on front mounting, overall size of the contactor is unchanged. Green Premium compliant (RoHS/REACh). · · · TeSys D suppressor module, for LC1D40A-D80A, LC1DT60A-DT80A contactors. · · To be used with 380-415V AC control circuit voltage, it provides a RC protection limiting the transient voltage to 3 Uc max. · · Clip-on front mounting, overall size of the contactor is unchanged. · · Compatibility code: LAD4 · · Green Premium compliant (RoHS/REACh). · · Ambient air temperature for storage: -40 to 80°C
Out of stock
Description
Technical Specifications Technical Specifications Surge protection module Rated control supply voltage at AC 50 Hz 110.00 – 240.00 V Rated control supply voltage at AC 60 Hz 110.00 – 240.00 V Rated control supply voltage at DC – – – V With LED indication No · Technical Data Sheet – Click to Download
