TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil
TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil
TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil - Image 2
TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil - Image 3
TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil - Image 4

TeSys K Contactor 3-Pole (3NO) AC-3 440V 12A 24V DC Coil

£71.88 Incl. VAT

TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides a low consumption 24V DC coil with transient suppressor module, 1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). · · · TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). · · Number of Poles: 3P · · It provides a low consumption 24V DC coil with transient suppressor module, 1NO built-in auxiliary contact, connection by screw clamp terminals. · · For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. · · Very compact (45mm width), DIN-rail mounting or screw fixing. · · Depth: 57mm · · Normal State Configuration: 3 No

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: LP4K1210BW3 Categories: , , Brand: Part Number: 2500246274

Description

Technical Specifications  Technical Specifications Power contactor, AC switching Rated operation power NEMA – kW Rated operation current Ie at AC-4, 400 V 6.00 A Rated operation power at AC-4, 400 V 2.20 kW Rated operation current Ie at AC-1, 400 V 20.00 A Rated operation current Ie at AC-3, 400 V 12.00 A Number of main contacts as normally open contact 3.00 Number of auxiliary contacts as normally closed contact 0.00 Rated operation power at AC-3, 400 V 5.50 kW Number of auxiliary contacts as normally open contact 1.00 Number of normally closed contacts as main contact 0.00 Rated control supply voltage at AC 50 Hz – – – V Rated control supply voltage at AC 60 Hz – – – V Rated control supply voltage at DC 24.00 – 24.00 V Modular version No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2187998
