TeSys K Contactor 3P AC-3 <= 440 V 12A, 1 NO aux., 110 V AC Coil
£87.19 Incl. VAT
TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (4kW@440V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 110V 50/60Hz AC coil,1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). · · · Designed to meet needs of various applications under 16A AC-3 · · Optimized size to save customer cabinet space · · Easier to install and operate with multi-standard screws · · Designed for zones sensitive to noise disturbed mains supplies (silent contactor: LC7K) · · Depth: 56mm · · IP Rating: IP67 / IP69K
Out of stock
Description
Technical Specifications Technical Specifications Power contactor, AC switching Number of main contacts as normally open contact 3 Number of normally closed contacts as main contact 0 Rated operation power NEMA – kW Rated operation power at AC-4, 400 V 2.2 kW Rated operation current Ie at AC-4, 400 V 6 A Rated operation current Ie at AC-3, 400 V 12 A Rated operation current Ie at AC-1, 400 V 20 A Rated operation power at AC-3, 400 V 5.5 kW Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as normally open contact 1 Rated control supply voltage at AC 50 Hz 110 – 110 V Rated control supply voltage at AC 60 Hz 110 – 110 V Rated control supply voltage at DC – – – V Modular version No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2187998
