Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm
Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm
Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm - Image 2
Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm - Image 3
Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm - Image 4

Through Connector. Copper Conductor: 150mm² Diameter: 16.7mm

£5.53 Incl. VAT

150mm² Copper tube through connector · · · Annealed to guarantee optimum ductility · · Facilitated introduction of the conductor · · -50°C to +150°C Temperature Range · · Maximum Voltage Rating: 11kV · · Manufactured from electrolytic Copper tube with a purity greater than 99.9% · · Electrolytically tin-plated to avoid oxidisation · · Fully Insulated: no · · CE: yes

45 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: L30-M Categories: , , Brand: Part Number: 2500046679

Description

Technical Specifications  Technical Specifications Crimp splices for copper conductor Voltage row Up to 600 V Insulation None Material Copper Sleeve form Long Type of connection Percussion connector Surface protection Tinned Model Standard version Nominal current – A AWG-range 300 – 250 Suitable for round conductors Yes Suitable for insulated varnish No Useful for stranded conductors Yes Suitable for flat conductors No Suitable for high temperatures (to 650 °C) No Nominal cross section 150 – 150 mm² Number of branches – Suitable for solid cores No For pull protected connections No Suitable for fine strand conductors Yes Oil stop/centre bar Yes · Technical Data Sheet – Click to Download
