Schneider Electric Trip Unit TM160D for ComPacT NSX 160/250 Circuit Breakers, Thermal Magnetic 160A 3 Pole 3d
£247.36 Incl. VAT
· · This TM160D is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 250 circuit breakers. · · This 160A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. · · It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. · · This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.
✓ In stock – Delivery in 1–2 days
Description
Technical Specifications Technical Specifications Trip block for power circuit-breaker Type of motor protection Thermal/magnetic release Short-circuit release function Undelayed Voltage type (operating voltage) AC Width 104.7 mm Height 60.6 mm Rated permanent current Iu 160 A Number of auxiliary contacts as normally closed contact 0 Number of auxiliary contacts as normally open contact 0 Number of auxiliary contacts as change-over contact 0 Rated switch current 160 A Number of poles 3 Depth 88.2 mm Overload release current setting 112 – 160 A Supply voltage AC 60 Hz – – – V Operating voltage at AC 50 Hz 690 – 690 V Supply voltage DC – – – V Operating voltage at AC 60 Hz 690 – 690 V Operating voltage at DC – – – V Current setting undelayed short-circuit release 1250 – 1250 A With ground fault protection function No External power supply required No · Technical Data Sheet – Click to Download · Manual: https://asset.eezybridge.com/ad7e7626-8f4a-4edb-b78d-9ca040e321dd/2205407
