Description

Product description

1. Key Specifications Module No. JD-1080HDR-210 Module Size 32*32MM(38*38) Temperature (Operation) -20°C to 70°C Pickup function Supports 2 electret microphones Assembly technique SMT (ROSH) Object distance 30CM-10000CM PCB printing ink Sinking gold and dumb black Focus mode FF interface USB2.0 Power USB bus power 5V Working current <160mA Operating system request WinDows Linux2.6.20 Android (Drivers standard) UVC driver free international standard Certifications ROSH (Electronic shutter mode) Rolling shutter Sensor Type 1/2.7” AR0230 Active Array Size 1920*1080 Sensitivity 4600mV/Lux-sec Pixel Size 1.4µm x1.4µm Maximum Image Transfer Rate 30FPS S/N Ratio 41% Dynamic Range 120DB HDR Lens Type TTL 15.7mm F/No 2.7 bFL 2.88mm FOV(D) 1.D:100°,H:85° 2: 210° TV Distortion <1% Optical Distortion <1% IR Filter 650±10nm DSP Type (White balance,exposure) Auto Output Formats YUV/MJPGE 1920*1080 : 30FPS/S 1600*1200 : 30fps 1280*720:30fps 800*600 :30fps 640*480:30fps

Key attributes

max. resolution 1080P
pixels 2 Mega
image sensor CMOS
interface type Usb
auto focus No
products status Stock
private mold Yes
place of origin Guangdong, China
model number RYS-1080HDR-210
brand name JIIND
Module Size 32*32MM(38*38)
Temperature (Operation) -20°C to 70°C
Pickup Function Supports 2 electret microphones
Assembly technique SMT (ROSH)
Operating system request WinDows Linux2.6.20 Android
Focus mode FF
interface usb 2.0
Active Array Size 1920*1080
Maximum Image Transfer Rate 30fps
Drivers standard UVC driver free international standard
Selling Units Single item
Single package size 1X1X1 cm
Single gross weight 0.150 kg
