Wago 2-Conductor Through Terminal Block With Lever And Push-In Cage Clamp 4mm With Test Port Suitable For Ex I Applications Side And Center Marking For Din-Rail 35 X 15 And 35 X 7.5 Push-In Cage Clamp 4,00 Mm Blue
£2.20 Incl. VAT
The 2104-1204 WAGO is a 2-pole, 4 mm terminal block with a lever and Push-in CAGE CLAMP®. It is made of gray thermoplastic and has a maximum current rating of 40 A. The terminal block is suitable for use with conductors with a cross-section of 4 mm². It has a test port and side and center marking. The terminal block is for DIN-rail 35 x 15 and 35 x 7.5. · · · 2-pole, 4 mm terminal block · · Lever and Push-in CAGE CLAMP · · Gray thermoplastic · · Maximum current rating of 40 A
Out of stock
Description
Technical Specifications Technical Specifications Feed-through terminal block Colour Blue Type of electrical connection 1 Spring clamp connection Type of electrical connection 2 Spring clamp connection Connectable conductor cross section fine-strand without cable end sleeve 0.5 – 0.5 mm² Rated current In 32 A Number of levels 1 Connectable conductor cross section fine-strand with cable end sleeve 0.75 – 0.75 mm² Connectable conductor cross section multi-wired 0.5 – 0.5 mm² Connectable conductor cross section solid-core 1.6 – 1.6 mm² · Technical Data Sheet – Click to Download
