Description

Technical Specifications  Technical Specifications Plug-in connector for plug-in building installation Model Plug Type of locking None Degree of protection (IP rating) IP20 Colour coding/contact insert White Housing material Polyamide (PA) Connection type Spring clamp connection Width 217 mm Pole codification L, N, PE Length 76 mm Rated current 25 A Rated voltage 250 V Pollution degree 3 Rated surge voltage 4 kV Continuity resistance 3 mOhm Max. continuous temperature resistance strain relief 85 °C Max. continuous temperature resistance contact part 85 °C Number of poles 3 Height 15 mm Number of connections per pole 2 Connection cross section (solid-core) 0.5 – 4 mm² Connection cross section (fine-strand) 5.4 – 4 mm² Cable diameter 8 – 11.5 mm Mechanical coding Yes With strain relief Yes Halogen free No · Technical Data Sheet – Click to Download
