Weidmuller SAK Polyamide 66 PE Terminal Block 36.5 x 6 x 46.5mm Green/Yellow
£6.28 Incl. VAT
This is a PE Terminal made of polyamide 66 with screw connection, PE connection and one end without connector. The Klippon connect provides a proven response to a range of different requirements. · · · High reliability · · Yoke connections make planning easer · · Optimises operational safety
Description
Technical Specifications Technical Specifications Earth terminal block Material insulation body Thermoplastic Colour Green/yellow Type of electrical connection 1 Screw connection Mounting method DIN rail (top hat rail)/G-rail TH35/G32 Number of clamp positions per level 2 Type of electrical connection 2 Screw connection Number of levels 1 Operating temperature -50 – 100 °C Connectable conductor cross section fine-strand with cable end sleeve 0.5 – 2.5 mm² Connectable conductor cross section multi-wired 0.5 – 2.5 mm² Connectable conductor cross section solid-core 0.5 – 4 mm² Connectable conductor cross section fine-strand without cable end sleeve 0.5 – 4 mm² PEN function possible No Closing plate required No · Technical Data Sheet – Click to Download
