Weidmuller Terminal 8-2AWG Polyamide 66 97g 16x67.5x58mm Green/yellow
Weidmuller Terminal 8-2AWG Polyamide 66 97g 16x67.5x58mm Green/yellow
Weidmuller Terminal 8-2AWG Polyamide 66 97g 16x67.5x58mm Green/yellow - Image 2

Weidmuller Terminal 8-2AWG Polyamide 66 97g 16×67.5x58mm Green/yellow

£14.17 Incl. VAT

Weidmuller 0354760000 green/yellow screwed TS 32 direct mounting modular PE terminal is made of PA 66 body. The EK 35 terminal contains no colour pigments based on heavy metals and do not lead to the formation of dioxin/furan. It features M6 clamping screw, 8 to 2AWG wire connection cross section, 4 to 6Nm tightening torque range and 8kV rated impulse withstand voltage to adjacent terminal. · · · Colour: Green/yellow · · Conductor Size: 8-2 AWG · · Height: 58mm · · Material: Polyamide 66 · · Width: 16mm · · Weight: 97g · · Depth: 67.5mm

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 354760000 Category: Brand: Product Code: 2500014383

Description

Technical Specifications  Technical Specifications Earth terminal block Mounting method G-rail Type of electrical connection 2 Screw connection Type of electrical connection 1 Screw connection Connectable conductor cross section fine-strand without cable end sleeve 10 – 35 mm² Connectable conductor cross section fine-strand with cable end sleeve 10 – 35 mm² Connectable conductor cross section solid-core 6 – 16 mm² · Technical Data Sheet – Click to Download
