Wylex 100A 100mA TYPE AC 4P RCD
Wylex 100A 100mA TYPE AC 4P RCD
Wylex 100A 100mA TYPE AC 4P RCD - Image 2

Wylex 100A 100mA TYPE AC 4P RCD

£108.18 Incl. VAT

A residual current circuit breaker; provide valuable additional protection to almost any type of installation by detecting earth fault current below the level sensed by traditional overcurrent device such as fuses of miniature circuit breaker. The RCD emp · · · Four Pole RCCB · · 100A 100mA · · Type AC · · For use with Wylex NH distribution boards · · For incoming options, can be used with NH4PINKIT connection kit · · Contact position indication on the dolly handle · · Terminal Capacity 35mm

Typically available in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: WRM100/4 Categories: , , Brand: Product Code: 2500055184

Description

Technical Specifications  Technical Specifications Residual current circuit breaker (RCCB) Rated fault current 0.1 A Width in number of modular spacings 4 Rated insulation voltage Ui 400 V Rated impulse-withstand voltage (Uimp) 4 kV Number of poles 4 Rated current 100 A Rated voltage 415 V With interlocking device No Additional equipment possible No Selective protection No
