Wylex C16 30mA 10kA 1P+N Type A RCBO (1MW) Long Tail

Description

Technical Specifications  Technical Specifications Earth leakage circuit breaker/RCBO Over voltage category 3 Number of protected poles 1 Rated short-circuit breaking capacity according to EN 61009 10 kA Rated impulse-withstand voltage (Uimp) 4 kV Rated current 16 A Width in number of modular spacings 1 Current limiting class 3 Rated fault current 0.03 A Number of poles (total) 1 Connectable conductor cross section solid-core 0.75 – 16 mm² Rated voltage 230 V Rated insulation voltage Ui 400 V Ambient temperature during operating -5 – 45 °C Concurrently switching N-neutral No With interlocking device No Connectable conductor cross section multi-wired 0.75 – 16 mm² Anti-nuisance tripping version No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
