Wylex MCB 16A SP Type C 10kA
Wylex MCB 16A SP Type C 10kA
Wylex MCB 16A SP Type C 10kA - Image 2
Wylex MCB 16A SP Type C 10kA - Image 3

Wylex MCB 16A SP Type C 10kA

£8.65 Incl. VAT

· · C curve trip characteristic (5-10In) · · Single Pole MCB · · 10kA to BS EN 60898-1 (15kA to BS EN 60947-2) @ 240V AC · · Energy limiting Class 3

Out of stock

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 6HSL16C Categories: , , Brand: Part Number: 2501514662

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Current limiting class 3 Over voltage category 3 Rated insulation voltage Ui 400 V Number of protected poles 1 Rated voltage 230 V Width in number of modular spacings 1 Rated current 16 A Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Flush-mounted installation No Concurrently switching N-neutral No Ambient temperature during operating -5 – 40 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Frequency 50 – 50 Hz Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Additional equipment possible No · Technical Data Sheet – Click to Download
