Wylex MCB 20A SP Type B 6kA
£4.62 Incl. VAT
This Miniature Circuit Breaker · · · Single pole MCB, 20A B curve · · Energy limiting Class 3 · · Plug in · · 6kA Fault Rating · · Suitable for use within Starbreaker Consumer Units · · Compliant with BS EN 60898 · · 25mm2 terminal capacity.
61 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Tripping characteristic (type/curve) B Rated voltage 230 V Over voltage category 3 Current limiting class 3 Number of protected poles 1 Rated insulation voltage Ui 400 V Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Width in number of modular spacings 1 Rated current 20 A Recess depth 73 mm Frequency 50 – 50 Hz Connectable conductor cross section multi-wired 0.75 – 25 mm² Ambient temperature during operating -5 – 40 °C Additional equipment possible No Concurrently switching N-neutral No Flush-mounted installation No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
