Wylex MCB 20A SP Type C 10kA
Wylex MCB 20A SP Type C 10kA
Wylex MCB 20A SP Type C 10kA - Image 2
Wylex MCB 20A SP Type C 10kA - Image 3

Wylex MCB 20A SP Type C 10kA

£24.64 Incl. VAT

· · C curve trip characteristic (5-10In) · · Single Pole MCB · · 10kA to BS EN 60898-1 (15kA to BS EN 60947-2) @ 240V AC · · Energy limiting Class 3

19 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 6HSL20C Categories: , , Brand: Part Number: 2501514663

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Current limiting class 3 Rated insulation voltage Ui 400 V Over voltage category 3 Width in number of modular spacings 1 Rated impulse-withstand voltage (Uimp) 4 kV Number of poles (total) 1 Number of protected poles 1 Ambient temperature during operating -5 – 40 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Frequency 50 – 50 Hz Rated current 20 A Rated voltage 230 V Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No · Technical Data Sheet – Click to Download
