Wylex MCB 20A SP Type C 6kA
Wylex MCB 20A SP Type C 6kA
Wylex MCB 20A SP Type C 6kA - Image 2
Wylex MCB 20A SP Type C 6kA - Image 3

Wylex MCB 20A SP Type C 6kA

£5.58 Incl. VAT

Type C (5-10IN) · · · Single pole MCB, 16A C curve · · Energy limiting Class 3 · · Plug in · · Number of Poles: Single Pole · · Terminal Capacity: 16 sq mm · · Voltage Rating: 240V · · Width: 18mm · · Depth: 70mm · · Frequency: 50Hz

8 available – delivery in 1–2 days

GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 61/C16 Categories: , , Brand: Part Number: 2500047525

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Recess depth 73 mm Rated current 16 A Tripping characteristic (type/curve) C Width in number of modular spacings 1 Rated voltage 230 V Rated insulation voltage Ui 400 V Current limiting class 3 Over voltage category 3 Number of protected poles 1 Ambient temperature during operating -5 – 40 °C Connectable conductor cross section multi-wired 0.75 – 25 mm² Frequency 50 – 50 Hz Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
