Crabtree 40A TP MCB Type C 10kA

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Rated current 40 A Rated insulation voltage Ui 400 V Rated voltage 230 V Number of poles (total) 3 Width in number of modular spacings 3 Rated impulse-withstand voltage (Uimp) 4 kV Current limiting class 3 Number of protected poles 3 Over voltage category 3 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Frequency 50 – 50 Hz Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Connectable conductor cross section multi-wired 0.75 – 25 mm² Ambient temperature during operating -5 – 40 °C Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No · Technical Data Sheet – Click to Download
