Wylex MCB 6A SP Type C 10kA

Description

Technical Specifications  Technical Specifications Miniature circuit breaker (MCB) Current limiting class 3 Rated insulation voltage Ui 400 V Over voltage category 3 Width in number of modular spacings 1 Rated current 6 A Number of protected poles 1 Frequency 50 – 50 Hz Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Rated voltage 230 V Connectable conductor cross section multi-wired 0.75 – 25 mm² Ambient temperature during operating -5 – 40 °C Concurrently switching N-neutral No Flush-mounted installation No Additional equipment possible No · Technical Data Sheet – Click to Download
