Wylex MCB 6A SP Type C 6kA
£5.58 Incl. VAT
BS EN 60898; 6kA – 240V 50Hz. Type C classification (5-10In). 16mmterminal capacity. · · · Single pole MCB, 6A C curve · · Energy limiting Class 3 · · Plug in · · Number of Poles: Single Pole · · Terminal Capacity: 16 sq mm · · Voltage Rating: 240V · · Width: 18mm · · Depth: 70mm · · Frequency: 50Hz
8 available – delivery in 1–2 days
Description
Technical Specifications Technical Specifications Miniature circuit breaker (MCB) Rated voltage 230 V Rated current 6 A Rated insulation voltage Ui 400 V Tripping characteristic (type/curve) C Number of protected poles 1 Rated short-circuit breaking capacity Icn EN 60898 at 400 V 6 kA Number of poles (total) 1 Rated impulse-withstand voltage (Uimp) 4 kV Recess depth 73 mm Width in number of modular spacings 1 Over voltage category 3 Current limiting class 3 Rated short-circuit breaking capacity Icn EN 60898 at 230 V 6 kA Frequency 50 – 50 Hz Connectable conductor cross section multi-wired 0.75 – 25 mm² Ambient temperature during operating -5 – 40 °C Additional equipment possible No Flush-mounted installation No Concurrently switching N-neutral No · Technical Data Sheet – Click to Download · Technical Data Sheet – Click to Download
